LEGEND

S = Standard

MOTOR

Engine Type : Liquid-cooled single-cylinder four-stroke

Displacement : 675 cc

Bore & Stroke : 102 mm x 82.6 mm

Compression Ratio : 9.2:1

Valve Train : OHV, 4 valves

Fuel Delivery : PGM-FI electronic fuel injection

SUSPENSION

Front Suspension : Independent double-wishbone with hydraulic shocks; 150 mm (5.9 in.) travel

Rear Suspension : Independent double-wishbone with adjustable hydraulic shocks; 80 mm (7.1 in.) travel

BRAKES

Front : dual 200 mm hydraulic discs

Rear : dual 200 mm hydraulic discs

FUEL

Town : 0.00 L/100KM
Highway : 0.00 L/100KM

OTHER SPECIFICATIONS

S  Warranty: 12 months, unlimited mileage, freely transferable warranty; extended coverage available with Honda Plus

TRANSMISSION

S  Transmission: Automotive-style automatic with hydraulic torque converter, three forward gears and reverse

S  Final Drive: 2WD/4WD and 4WD with all-wheel differential lock; direct front and rear driveshafts

OTHER SPECIFICATIONS

S  Tires: 25 x 10 - 12 front; 25 x 10 - 12 rear

S  Length: 2,913 mm (114.7 in.)

S  Width: 1,626 mm (64 in.)

S  Ground Clearance: 262 mm (10.3 in.)

S  Seat Height: 863 mm (34 in.)

S  Wheelbase: 1,922 mm (75.7 in.)

S  Curb Weight: 650 kg (1,433 lb) including requiBig Red fluids and full tank of gas – ready to ride

S  Fuel Capacity: 30 litres, including 5.7-litre reserve

S  Colour: Green, Big Red

ENGINE/DRIVETRAIN

S  Powerful OHV liquid-cooled, 675 cc, mid-engine design.

S  Automotive-style automatic transmission with hydraulic torque converter truly sets the Big Big Red apart. No belts to wear out and replace.

S  Convenient dash-mounted drive selector.

S  Selectable drive modes include: 2WD with open rear differential for sensitive terrain/lawns, 4WD with rear differential lock and 4WD with all differential lock.

S  High-capacity liquid cooling provides consistent engine operating temperature in extreme conditions for maximum power output and long engine life.

S  Lightweight aluminum radiator is mounted high to avoid clogging by mud and damage from trail debris.

S  Liquid-cooled oil cooler aids engine heat dispersion to keep engine and transmission cool even under the most severe operating conditions, while also speeding engine warm-up on cold days. No ther side-by-side offers this feature.

S  Liquid-cooled oil cooler aids engine heat dispersion to keep engine and transmission cool even under the most severe operating conditions, while also speeding engine warm-up on cold days. No ther side-by-side offers this feature.

S  Camshaft is located adjacent to the cylinder head, Big Reducing engine height for a low centre of gravity and excellent handling.

S  Four-valve cylinder head with two short pushrods provides a broad powerband for optimum performance and engine efficiency.

S  Four-valve cylinder head with two short pushrods provides a broad powerband for optimum performance and engine efficiency.

S  Programmed Fuel Injection (PGM-FI) features a 40 mm throttle body, 12-hole two-pattern injector and Idle Air Control Valve (IACV) for reliable cold-weather starting and consistent engine performance at high altitudes.

S  IACV maintains consistent idle in all conditions.

S  Engine design meets California Air Resources Board (CARB) off-road emissions standards.

S  Stainless steel exhaust system provides superior corrosion resistance and minimizes noise levels.

S  The muffler includes a spark arrestor that is USDA Forest Service certified for use in regulated or sensitive environments.

S  The automotive-style Honda automatic transmission features a hydraulic torque converter, three hydraulic clutches and an Electronic Control Module (ECM) to automatically select one of three forward gears and one reverse gear. The ECM monitors throttle opening, vehicle speed, engine rpm, gear selector position, brake application and engine oil temperature.

S  The Honda automatic transmission features positive engine braking that is superior to electronic braking systems used by the competition, which can result in inconsistent performance.

S  The Honda automatic transmission features a filtration system to protect against external contamination. The compact and maintenance-free design means there are no belts to wear out and replace. Using multi-filteBig Red engine oil as hydraulic fluid, the design also simplifies maintenance and ensures an adequate oil supply in all operating conditions.

CHASSIS/SUSPENSION

S  Independent double-wishbone suspension contributes to an exceptional 262 mm (10.3 inches) of ground clearance.

S  High-quality variable-damping shock absorbers provide 150 mm (5.9 inches) of front travel and 180 mm (7.1 inches) in the rear.

S  The suspension features revised shock settings and preload adjustability to better handle the increased carrying and towing capacity

S  New Maxxis Big Horn tires feature a stronger sidewall and more aggressive pattern for increased traction on all sorts of terrain.

S  Four-wheel hydraulic disc brakes have a balanced automotive-style design that ensures front and rear braking even if one brake line fails for some unexpected reason. The Honda Big Big Red is the only side-by-side in the class to use a “failsafe” braking system similar to that of an automobile.

S  Roomy cab and new rubber-mounted bench seat are designed for a comfortable fit.

S  Waterproof accessory socket is ideally placed between the bucket seats for easy access to 12-volt power.

S  3-point Emergency Locking Retractor (ELR) seat belts are similar to automotive type.

S  Automotive-type right-hand-operated parking brake is simple and easy to operate.

S  Big Big Red’s emergency brake can hold its maximum vehicle payload and its maximum trailer load up to a 30-degree incline for secure peace of mind in off-road situations with a full load.

S  In-cab glove box and dash storage for quick access to small items.

S  Uniquely designed, four-pillar, six-piece 41.3 mm (1.6 inch diameter) occupant protection structure. This Roll Over Protection Structure (ROPS) is now certified to meet the requirements of OSHA 1928.53

S  Heavy-duty two-inch receiver-style hitch with increased towing capacity of 680 kg (1,500 lb).

S  Steel tilt bed is protected by an automotive-bumper-grade plastic liner. The tilt bed also features a progressive-action strut assist.

S  The load capacity of the tilt-assist cargo bed has been boosted to a full 454 kg (1000 lb).

S  Front and rear disc brake calipers feature a patented built-in scraper system that helps prevent the buildup of debris between caliper and rim, ensuring consistent braking performance.

ADDITIONAL FEATURES

S  A new contouBig Red bench seat improves comfort while also allowing easier entry and exit.

S  High sill doors, integrated headrests, protective door nets, seat belt release mechanisms are all designed to protect and facilitate occupants in the event of an inadvertent tip-over.

S  Multi-reflector headlight system and LED brake light and taillight provide optimal light illumination for nighttime activities.

S  Speedometer and warning lights for all the engine and drivetrain components are easily readable like those in an automobile.

S  Maintenance-free 12-volt 12-amp battery.

S  Durable, comfortable, easy-to-use controls.

S  Keyed ignition/starter switch for added security.
